Hot item
E-Gear
E-Gear Titanium Halligan
«Main Features«
- Lightweight Design [about half (or less) the weight of a standard steel tool] -
- Add equipment with the weight savings of the Titanium Tool -
- High Yield & Tensile Strength -
- Effortless Stair Climbing -
- Low Electrical Conductivity -
- Low Thermal Conductivity -
- Water & Seawater Corrosion Resistance -
- Corrosion Resistant to most chemicals & Needs No Oiling -
«Specification«
Material: Grade C-5 Titanium, meets standard ASTM B 367-13 and ASTM F 1472-14
Length
Weight (kg)
Weight (lbs)
24 Inches
2.12
4.67
±5%
36 Inches
2.84
6.26
±5%
«Color«
Black, Silver
«Other Options«
***Tailor-made size (e.g., 30”) available***
***Please consult our sales team for more details***
ADD TO QUOTE
View product
New item
E-Gear
Optical Rescue & Escape Light Line System
= OPTICAL FIBER FIRE RESCUE LIGHTING LINE =
In environments with low visibility such as fire and smoke, the luminous wire used t o guide the escaperoute, which consists of a power supply system, a luminous line body, and a winding turntable.
«Main Features«
- Optical fiber transmission -
- Photoelectric separation technology -
- Free surface accurate light distribution -
- Uncharged light cable, can be used underwater -
- Continuous luminous brightness not less than 10cd/m2 -
- Choice of length: 50m / 100m / 200m / 300m / 500m -
- Type of system: Conventional / Explosion Proof / Communication / Portable (Customised) -
«Light Line Structure«
«Application Scenarios«
= BUILDING RESCUE =
= UNDERGROUND PASSAGE RESCUE =
= UNDERWATER RESCUE =
«Specification«
Size
305 x 215 x 406mm (conventional 100m / 200m / 300m type)
293 x 214 x 400mm (explosion proof 100m / 200m type)
200 x 200 x 100mm (portable 50m type, by customization only)
Line Diameter
3.5mm (conventional type)
4.6mm (communiction type)
Weight
4.5kg±2% (conventional 100m type)
5.6kg±2% (explosion proof 100m type)
>2kg (portable 50m type)
Luminous Material
SiO2
Line Material
Quartz fiber, Steel wire rope, Plastic PVC
Line Length
50m / 100m / 200m / 300m / 500m
Continuous operationg hours
>14 hours (constant-on)>28 hours (flash)
Photoelectric conversion efficency
30~35%
Battery Type
Rechargable Li-ion Battery
Battery Capacity
10.4Ah
Operating voltage
Input DV12V, 0V
Line working current
0V
Flashing Frequency
1.5Hz
Tensile Strength
>1100N (metal wire only)
Compressive Strength
Pass
Waterproofness
IP66 (conventional type)
IP67 (explosion proof type)
Max surface temperature
No temperature rise (same as environmental temperature)
Certification
GB 26783-2011
Ex ic op is IIC T4 Gc (explosion proof type only)
Ex op is tc IIIC T130℃ Dc (explosion proof type only)
ADD TO QUOTE
View product
