E-Gear
Optical Rescue & Escape Light Line System
= OPTICAL FIBER FIRE RESCUE LIGHTING LINE =
In environments with low visibility such as fire and smoke, the luminous wire used t o guide the escaperoute, which consists of a power supply system, a luminous line body, and a winding turntable.
«Main Features«
- Optical fiber transmission -
- Photoelectric separation technology -
- Free surface accurate light distribution -
- Uncharged light cable, can be used underwater -
- Continuous luminous brightness not less than 10cd/m2 -
- Choice of length: 50m / 100m / 200m / 300m / 500m -
- Type of system: Conventional / Explosion Proof / Communication / Portable (Customised) -
«Light Line Structure«
«Application Scenarios«
= BUILDING RESCUE =
= UNDERGROUND PASSAGE RESCUE =
= UNDERWATER RESCUE =
«Specification«
Size
305 x 215 x 406mm (conventional 100m / 200m / 300m type)
293 x 214 x 400mm (explosion proof 100m / 200m type)
200 x 200 x 100mm (portable 50m type, by customization only)
Line Diameter
3.5mm (conventional type)
4.6mm (communiction type)
Weight
4.5kg±2% (conventional 100m type)
5.6kg±2% (explosion proof 100m type)
>2kg (portable 50m type)
Luminous Material
SiO2
Line Material
Quartz fiber, Steel wire rope, Plastic PVC
Line Length
50m / 100m / 200m / 300m / 500m
Continuous operationg hours
>14 hours (constant-on)>28 hours (flash)
Photoelectric conversion efficency
30~35%
Battery Type
Rechargable Li-ion Battery
Battery Capacity
10.4Ah
Operating voltage
Input DV12V, 0V
Line working current
0V
Flashing Frequency
1.5Hz
Tensile Strength
>1100N (metal wire only)
Compressive Strength
Pass
Waterproofness
IP66 (conventional type)
IP67 (explosion proof type)
Max surface temperature
No temperature rise (same as environmental temperature)
Certification
GB 26783-2011
Ex ic op is IIC T4 Gc (explosion proof type only)
Ex op is tc IIIC T130℃ Dc (explosion proof type only)
ADD TO QUOTE
View product
Hot item
E-Tac
E-TAC Protective Gloves 3365TR
= SUITABLE FOR RAPPELLING, RESCUE & EXTRICATION EMERGENCY SERVICE =
East Gear Protective Gloves designed against mechanical risk & thermal risk.
«Main Features«
-Tight fitting -- Curved fingers -- Medium duty industrial use -- Elastic, breathable, flexible, better dexterity -- Carabiner hole to attach gloves to harness -- Palm padded in high wear areas to protect from heat generated during long rappels or lowers -- Meet the essential requirements of the Personal Protective Equipment Regulation 2016/425 -
«Specification«
Size:
XS/6, S/7, M/8, L/9, XL/10, 2XL/11, 3XL/12
Material:
Palm Region: Black Goatskin with goatskin reinforcement
Palm Liner: Fleece
Backhand Region: Black Goatskin, integrated with Spandex & Polyester Knuckle
Cuff Region: Neoprene, equipped with Velcro Fastener
«Color«
All Black
«Other Options«
***Other Colors may be available***
***Please consult our sales team for more details***
ADD TO QUOTE
View product
New item
E-Gear
E-Gear Multipurpose Moving Platform
= MultiPurpose Moving Platform =
E-Gear Multipurpose Moving Platform is a multifunctional, portable, and practical moving equipment.
The unique folding body design, large carrying capacity, and standardized interface allow the platform to be carried in vehicles to assist fire and rescue departments in emergency vehicle relocation and heavy object transport.
It can also be quickly equipped with various functional modules, serving as a multi-functional transportation tool for firefighting, fire detection, smoke extraction, bomb disposal, and lighting.
«Main Features«
- Compact in size -
- Modular design -
- Crawler track design -
- 360° turning -
- Direction lights -
- Radar detector for anti-collision -
- Environmental temperature detection -
- GPS/Beidou dual-mode positioning -
- Real time remote control and video transmission in a 4G network -
- Multiple devices connection -
- Optional functions/accessories:
- Extension Rack, Water Cannon, Gas Detector, TIC -
«Video Demo: Extinguishing EV Fire«
«Specification«
Size (W X L X H)
1115 x 1115 x 400 mm (±2%)
Weight
≤180kg ±2%
Loading Weight
2500 kg (max. 3000 kg)
Max. Speed
≥0.9m/s
Lifting Height
120mm ~ 400mm
Lifting Speed
≥12mm/s
Platform Turning Speed
4.2°/s
Moving Distance
≥2km (Loaded); ≥10km (Unloaded)
Sloping Angle
≤8° (Loaded) ; ≤20° (Unloaded)
Max. Obstacle Height
40mm
Power
DC48V, 1.5kWh rechargeable lithium-ion Built-in Battery
Standby Time
≥120 hours
Continuous Working Time
≥5 hours
Operating Temperature
-20℃ ~ 60℃
Storage Temperature
-40℃ ~ 70℃
Relative Humidity
0% ~ 90%
IP Rating
IP65
ADD TO QUOTE
View product
