E-Gear
RHJ800
= ALARMA DE SEGURIDAD PERSONAL PARA RESCATE EN CASO DE INCENDIO, BÚSQUEDA Y RESCATE, EXPLORACIÓN DE TÚNELES Y OTROS TRABAJOS EN ESPACIOS CONFINADOS丨RHJ800 =
La alarma de bomberos HJ800 es pequeña en tamaño y robusta en estructura. Es un equipo de alarma de emergencia esencial para el personal que trabaja en situaciones peligrosas.
Puede realizar funciones como llamadas de socorro y alarmas in situ.
Cumple con la norma GB27900-2011 «Firemen's SOS».
«Main Features«
- SOS -
- Temporizador -
- Iluminación -
- Pantalla LCD -
- Alarma manual -
- Alarma de parada -
- Luz de orientación -
- Interruptor de llave rápida -- Prealarma estática -- Alarma de batería baja -- Alarma de alta temperatura -- Registro rápido de ID -
«Specification«
Talla
68×109×45mm
Pesp
≤200g
Intensidad del nivel sonoro de prealarma
102dB
Intensidad del nivel sonoro de la alarma
102dB
Tiempo de alarma continuo
800 min
Tiempo de espera
200hr
Grado antideflagrante
Ex ia IIC T3 Ga
Batería
1200mAh
Tensión de funcionamiento
7.4V DC
Temperatura de funcionamiento
-25℃~ 70℃
Humedad relativa
95%RH
ADD TO QUOTE
View product
New item
E-Gear
Optical Rescue & Escape Light Line System
= OPTICAL FIBER FIRE RESCUE LIGHTING LINE =
In environments with low visibility such as fire and smoke, the luminous wire used t o guide the escaperoute, which consists of a power supply system, a luminous line body, and a winding turntable.
«Main Features«
- Optical fiber transmission -
- Photoelectric separation technology -
- Free surface accurate light distribution -
- Uncharged light cable, can be used underwater -
- Continuous luminous brightness not less than 10cd/m2 -
- Choice of length: 50m / 100m / 200m / 300m / 500m -
- Type of system: Conventional / Explosion Proof / Communication / Portable (Customised) -
«Light Line Structure«
«Application Scenarios«
= BUILDING RESCUE =
= UNDERGROUND PASSAGE RESCUE =
= UNDERWATER RESCUE =
«Specification«
Size
305 x 215 x 406mm (conventional 100m / 200m / 300m type)
293 x 214 x 400mm (explosion proof 100m / 200m type)
200 x 200 x 100mm (portable 50m type, by customization only)
Line Diameter
3.5mm (conventional type)
4.6mm (communiction type)
Weight
4.5kg±2% (conventional 100m type)
5.6kg±2% (explosion proof 100m type)
>2kg (portable 50m type)
Luminous Material
SiO2
Line Material
Quartz fiber, Steel wire rope, Plastic PVC
Line Length
50m / 100m / 200m / 300m / 500m
Continuous operationg hours
>14 hours (constant-on)>28 hours (flash)
Photoelectric conversion efficency
30~35%
Battery Type
Rechargable Li-ion Battery
Battery Capacity
10.4Ah
Operating voltage
Input DV12V, 0V
Line working current
0V
Flashing Frequency
1.5Hz
Tensile Strength
>1100N (metal wire only)
Compressive Strength
Pass
Waterproofness
IP66 (conventional type)
IP67 (explosion proof type)
Max surface temperature
No temperature rise (same as environmental temperature)
Certification
GB 26783-2011
Ex ic op is IIC T4 Gc (explosion proof type only)
Ex op is tc IIIC T130℃ Dc (explosion proof type only)
